Condition : New
Horsepower : 251 - 350hp
Emission Standard : Euro 3
Brand Name : Dongfeng Tipper Truck
Model Number : DFL3258A3
Place of Origin : Hubei, China
Fuel Type : Diesel
Engine Capacity : > 8L
Transmission Type : Manual
Dimensions (L x W x H) (mm) : 8470*2500*3484
Gross Vehicle Weight : 25000
Capacity (Load) : 31 - 40T
Drive Wheel : 6x4
Color : Cherry Red, Yellow, Blue, White
Frame : 300*80*80mm(inner 280*70*7mm)
Tyre : 12R22.5
Offical Website : www.runlitruck.com
Chasis optional : Sinotruck HOWO, BEIBEN NORTH BENZ,FOTON,DONGFENG DFL,Hino,Jiefang Faw
Driving Type : 4*2 , 4*4,6*4, 6*6,8*4,8*4 All Wheel Drive Off Raod
Packaging Details : naked package , waxed before delivery, Shipping by RORO or Bulk shipment, please directly contact with Ms Pinky. Hotline:0086 15897603919
Port : Shanghai,Tianjin,longkou or other china port
Supply Ability : 200 Unit/Units per Month
MOQ : 2 units
Price : CN¥274,766.60-353,581.23/units
35Tons Tipper Truck Dongfeng 10 Wheels DFL Dumper Call 0086 15897603919
The specification of Dongfeng 10 Wheels 35Tons Tipper Truck:
Application conditions: steel, iron ore, iron ore mining, iron ore and other high density in short-distance transport and short-distance transport of goods.
The Dumper truck features: Dongfeng New cabin Heavy duty dumper truck using the Cummins engine, large capacity, strong power, large torque at low speed, low fuel consumption, high reliability; the Shaanxi teeth 9 forwards transmission, convenient operation, high strength, long service life of the gear; the use of 13 tons of Dongfeng wheel reducer bridge, steel bridge shell, strong carrying capacity, large clearance, good passing ability, can fully meet the iron powder, iron ore short-distance transport, suitable for mountain road, road, road transport.
| Technical parameter of chassis DFL3258A3 | |||
| outside dimension (L×W×H)mm | 8300×2500×3450 | ||
| Total mass | Kg | 42,060 | |
| Loading mass | Kg | 30,000 | |
| Kerb mass | Kg | 11,910 | |
| Chassis Model /Manufacturer | DFL3258A3 | ||
| driving type | 6×4 | ||
| Cabin | Flat head, tippable, one bed(D310-S1) | ||
| Wheelbase | mm | 3800+1450 | |
| Front overhang / rear overhang | mm | 1500/1550 | |
| Front tread / rear tread | mm | 2040, 1850/1850 | |
| Approach angle /Departure angle | 30/28 | ||
| Engine | |||
| model | L340 30 | L290 30 | |
| Max. power/rotated speed | 250(KW) /2200(rpm) | 213KW/2200rpm | |
| Type of fuel | Diesel | diesel | |
| Company of engine | Dongfeng Cum,mins Engine | ||
| Gear box FAST RT-11509G | |||
| clutch | Φ430mm diaphragm spring clutch | ||
| Front axle | 7T | ||
| Rear axle | 16T×2 | ||
| Tyre | 12.00R0 | ||
| Max Speed | 90Km/h | ||
| air condition | With | ||
| Cargo body | 5600×2300×1200mm | ||








our Tipper Truck Producing workshop:




Welcome to Visit our factory in Suizhou City Hubei Province!

|
|
35Tons Tipper Truck Dongfeng 10 Wheels DFL Dumper Images |
